How To Remove The Notorious Turbo Manifold Nut!!
« on: 01:50:35 PM / 03-Sep-08 »
Hey.  Mods if this should go to the how to, feel free to move it there, if not, dont.   I wasnt quite sure what should be done, guess it can be found if searched for.  Anyway I think this will make for a nice guide to getting that nut off...

Anyway, I just bought my 85 turbo hatch with a blown turbo and major exhaust leak...  So, pulling the turbo was in order.  Getting everything off is basically easy, the banjo bolt behind the turbos kinda rough and getting the downpipe off was annoying but not to big a deal.

Untill I got to the lower, rearmost head to manifold nut.  I searched and found that people cut a wrench halfway or bent one to fit properly to get it off.  I tinkered with it for a while, checked to see if there was access from the bottom, untill I remembered I had this.





Yes its a 9/16th's wrench, but in a pinch it works damn well.  Its bent at roughly 180 degrees.

Still takes some patience but no contorting of body parts necessary.   Hope this helps.

Sincerely Tyler/
« Last Edit: 01:52:40 PM / 03-Sep-08 by tjs91tsi »

Facebook Share


Offline RB25sx - SLPR

  • Full Member
  • ***
  • Location: Victoria BC, Canada
  • Posts: 857
How To Remove The Notorious Turbo Manifold Nut!!
« Reply #1 on: 02:58:39 PM / 03-Sep-08 »
That is the greatest tool ever invented..




Offline SprockCapn

  • Sr. Member
  • ****
  • Location: Billings, MT USA
  • Posts: 1,001
How To Remove The Notorious Turbo Manifold Nut!!
« Reply #2 on: 03:55:53 PM / 20-Jan-09 »
I was just curious as I'm having to deal with this now. I'm pretty sure all of the other bolts are 14mm not 9/16. This is the last bolt that i need to get too I just wanted to make sure and get the right tool.

Offline kyskater

  • Full Member
  • ***
  • Location: Russellville ky
  • Posts: 984
    • http://
How To Remove The Notorious Turbo Manifold Nut!!
« Reply #3 on: 11:02:44 PM / 20-Jan-09 »
9/16 is practiclly a 14 just a few thousands off


Quote from: Arro
hahah NIPPLES, sam. Nipples!

Offline SprockCapn

  • Sr. Member
  • ****
  • Location: Billings, MT USA
  • Posts: 1,001
How To Remove The Notorious Turbo Manifold Nut!!
« Reply #4 on: 11:25:23 PM / 20-Jan-09 »
Quote from: kyskater
9/16 is practiclly a 14 just a few thousands off

Do you by chance know what the tool is called and where I can possibly find one. I have been all over looking for one. Thanks

Offline EightySix200SX

  • low.fun.sexytime!
  • S12 Guru
  • *****
  • Location: SoCal, CA.US/BajaNorte, TJ.MEX
  • Posts: 5,218
  • Vehicle: 1986 Nissan 200SX
  • NEED ANYTHING S12 RELATED PM or Email today!
    • «LOW.XII.POSITION» INTL PARTS SALES/DISTRIBUTION
How To Remove The Notorious Turbo Manifold Nut!!
« Reply #5 on: 11:39:28 PM / 20-Jan-09 »
lol i hope i sont have to do this it was still troublesome with the motor out lol
«LOW.XII.POSITION».nostalgic car culture & club ¦est.2004
¡lowfunsexytime! Global New & Used Parts Sales/Distribution

CLUB-S12 FEEDBACK RATING +72! CLICK HERE
ANYTHING  LOOKIKG FOR :  PARTS IN STOCK CLICK HERE
NEED S12 PARTS NOT LISTED IN MY THREAD? EMAIL lowXIIposition@yahoo.com OR Facebook US: www.facebook.com/need12parts/
I <3 DEMI LOVATO= ID SMASH! SELENA GOMEZ/MILEY CYRUS= R TRASH!

Damn let a Nig have a moment of glory b4 you start fucking with him.

Offline Draconis

How To Remove The Notorious Turbo Manifold Nut!!
« Reply #6 on: 01:07:16 AM / 21-Jan-09 »
That sure could have been helpful.  Ah well, my knuckles/fingers were too frozen to feel much anyway.

Offline nismologist

  • S12 Guru
  • *****
  • Location: Sacramento,California
  • Posts: 3,541
    • http://
How To Remove The Notorious Turbo Manifold Nut!!
« Reply #7 on: 02:35:03 AM / 21-Jan-09 »
you can get the tool ina mac catalouge

YOU THOUGHT SO, BUT I KNOW SO.
-Macho Man Randy Savage

Offline Draconis

How To Remove The Notorious Turbo Manifold Nut!!
« Reply #8 on: 02:39:52 AM / 21-Jan-09 »
Quote from: nismologist
you can get the tool ina mac catalouge
Thanks man!  But with the Mac on the tool I think we *maybe* could have figured that out.

Offline Arro

  • Administrator
  • S12 Guru
  • *****
  • Location: San Jacinto, CA, USA (951)
  • Posts: 16,885
  • Vehicle: 1985 Nissan 200SX
    • http://www.cardomain.com/id/arro200sx
How To Remove The Notorious Turbo Manifold Nut!!
« Reply #9 on: 12:24:05 AM / 30-Jan-09 »
OMFG I hated that part when I was installing my turbo on my CA18ET... I ended up going with stubby closed wrenches, the effect was the same, but the control is a bit better....



I think given the need now, I'd go with these ratcheting ones:



...or make your own, like I think Bart or someone else on here did:

-Jason Arro


'85 Nissan 200SX (KA24DE)
formerly,
'85 Nissan Silvia RS-X - FJ20 w/ dual Weber carbs
'84 Nissan 200SX Turbo
'85 Nissan 200SX Turbo
Drive it like you stole it, and work on it like you married it - self quote
Quote from: ka-t.org
Hella flush and all associates should be gunned down for brainwashing people into thinking a 225 and lots of camber is proper wheel fitment. THAT IS EASY, anyone can camber a skinny as tire till it dosnt rub. Now fitting an 11 with a 315 on stock fender with reasonable camber, that is fitment. And looks, and performs better than both.
i dont own a s12 at the moment but trying to acquire one to get rid of my s13 hatch
Quote from: SHOUTBOX
[27:54] zastaba: I had a friend touch the contacts on his distributer once
[28:04] zastaba: He did the super jumping up and down pain dance

Offline sideways_s12

  • CS12 OG
  • Moderators
  • S12 Guru
  • *****
  • Location: Las Vegas NV
  • Posts: 11,013
  • Vehicle: 1987 Nissan 200SX
  • Quit Fuckin around and start the car!
How To Remove The Notorious Turbo Manifold Nut!!
« Reply #10 on: 04:09:03 AM / 30-Jan-09 »
yup waylon and I made our own haha Man I can't wait to get that top mount from bart it'll be sooooooooooooooooooooooooooo much easier to get to that nut haha

Offline SprockCapn

  • Sr. Member
  • ****
  • Location: Billings, MT USA
  • Posts: 1,001
How To Remove The Notorious Turbo Manifold Nut!!
« Reply #11 on: 12:40:53 PM / 01-Feb-09 »
Quote from: Arro
OMFG I hated that part when I was installing my turbo on my CA18ET... I ended up going with stubby closed wrenches, the effect was the same, but the control is a bit better....



I think given the need now, I'd go with these ratcheting ones:



...or make your own, like I think Bart or someone else on here did:



I think I'm retarded. I have these tools and never once thought of the stubby tools! I thought about cutting one but forgot about the stubby wrenches. I'm going to go try those right now. Wish me luck.

Offline Arro

  • Administrator
  • S12 Guru
  • *****
  • Location: San Jacinto, CA, USA (951)
  • Posts: 16,885
  • Vehicle: 1985 Nissan 200SX
    • http://www.cardomain.com/id/arro200sx
How To Remove The Notorious Turbo Manifold Nut!!
« Reply #12 on: 12:05:57 AM / 02-Feb-09 »
yeah the stubbies worked for me on my CA18ET.  I wish I had those ratcheting ones tho at the time, those are nice! Good luck
-Jason Arro


'85 Nissan 200SX (KA24DE)
formerly,
'85 Nissan Silvia RS-X - FJ20 w/ dual Weber carbs
'84 Nissan 200SX Turbo
'85 Nissan 200SX Turbo
Drive it like you stole it, and work on it like you married it - self quote
Quote from: ka-t.org
Hella flush and all associates should be gunned down for brainwashing people into thinking a 225 and lots of camber is proper wheel fitment. THAT IS EASY, anyone can camber a skinny as tire till it dosnt rub. Now fitting an 11 with a 315 on stock fender with reasonable camber, that is fitment. And looks, and performs better than both.
i dont own a s12 at the moment but trying to acquire one to get rid of my s13 hatch
Quote from: SHOUTBOX
[27:54] zastaba: I had a friend touch the contacts on his distributer once
[28:04] zastaba: He did the super jumping up and down pain dance

Offline tjs91tsi

  • Full Member
  • ***
  • Location: Tucson, Az.
  • Posts: 107
    • http://
How To Remove The Notorious Turbo Manifold Nut!!
« Reply #13 on: 07:28:24 PM / 05-Feb-09 »
Sorry yes, it is technically a 14mm.  A 9/16th "works." While I never recommend or say that metric and standard are interchangeable, im sure the little bit of extra freeplay was helpfull in getting it on and off.

I dont have any junk or cheapo tools to cut and I remembered I had that so I tried it.  It worked flawlessly.  I had no problems at all, once I got the rythm down, the nut went right on.  (thats what she said)  lol Sorry.

Tyler.

Offline Julie

  • S12 Guru
  • *****
  • Posts: 4,890
    • http://
How To Remove The Notorious Turbo Manifold Nut!!
« Reply #14 on: 07:43:25 PM / 05-Feb-09 »
i think im gonna buy a set of those ratcheting wrenches before i install my ET's turbo


"like people, every car possesses a unique character, with its own DNA, talents, and idiosyncrasies. push it too hard and it'll turn on you, as a person would. if its worth anything, it gets more interesting the more you get to know it"

luck is earned through hard work and determination, not to mention the willingness to take risks and to see bad luck and setbacks as opportunities for growth and a new direction.

Offline EightySix200SX

  • low.fun.sexytime!
  • S12 Guru
  • *****
  • Location: SoCal, CA.US/BajaNorte, TJ.MEX
  • Posts: 5,218
  • Vehicle: 1986 Nissan 200SX
  • NEED ANYTHING S12 RELATED PM or Email today!
    • «LOW.XII.POSITION» INTL PARTS SALES/DISTRIBUTION
How To Remove The Notorious Turbo Manifold Nut!!
« Reply #15 on: 11:09:30 AM / 06-Feb-09 »
i dont know yalls pain yet. as i did all the gaskets on my motor set so hopefully i wont have to touch it for some time. i did all them out of the car even then that nut i can see will still be a bitch.
«LOW.XII.POSITION».nostalgic car culture & club ¦est.2004
¡lowfunsexytime! Global New & Used Parts Sales/Distribution

CLUB-S12 FEEDBACK RATING +72! CLICK HERE
ANYTHING  LOOKIKG FOR :  PARTS IN STOCK CLICK HERE
NEED S12 PARTS NOT LISTED IN MY THREAD? EMAIL lowXIIposition@yahoo.com OR Facebook US: www.facebook.com/need12parts/
I <3 DEMI LOVATO= ID SMASH! SELENA GOMEZ/MILEY CYRUS= R TRASH!

Damn let a Nig have a moment of glory b4 you start fucking with him.

Offline SprockCapn

  • Sr. Member
  • ****
  • Location: Billings, MT USA
  • Posts: 1,001
How To Remove The Notorious Turbo Manifold Nut!!
« Reply #16 on: 11:18:46 AM / 06-Feb-09 »
I got one from sears that is not the complete 180 and it is not turned enough. I can't seem to find that one here and the only MAC ones I can find are a set for like $250. So well see. I'm gonna have to figure out how to get it all the way off since I'm gonna re-tap the holes for the studs so they are deeper and do new gaskets on that side. So well see. I wish I could just find that one stupid tool in town!

Offline Cajun1guy

  • Old fart (pedoro numero uno)
  • Full Member
  • ***
  • Location: Mandeville, Lousyana
  • Posts: 756
  • Vehicle: 1984 Nissan 200SX
How To Remove The Notorious Turbo Manifold Nut!!
« Reply #17 on: 09:38:32 PM / 08-Feb-09 »


I hope I did this right! I use a Snap-On wrench, SBXM 1415 and I cut off the 15 mm boxend to clear the firewall. Works great for me, real easy to get max torque.

oh well, link gets you there. Still don't get the picture thing..

Moderator Edit: next time, use [img] on either side of the link to display the image in the post.except that the one on the end is /img and in brackets.
« Last Edit: 12:14:45 AM / 09-Feb-09 by Arro »

Offline street_ruler

  • Full Member
  • ***
  • Posts: 261
How To Remove The Notorious Turbo Manifold Nut!!
« Reply #18 on: 09:15:08 PM / 18-Mar-09 »
if anyone wants to know, that tool that is saped in a HALF MOON is called a HALF MOON wrench.

common for ford and chevy starters mostly.  good luck finding one in metric but 9/6ths is dead on for 14mm
Crew chief:  \"the upper shock tower mount just broke.  the strut could come right through the hood.\"

DC:  *looks at pile of spare parts* \"its cool.  i got another hood.  lets race\"

Offline SprockCapn

  • Sr. Member
  • ****
  • Location: Billings, MT USA
  • Posts: 1,001
How To Remove The Notorious Turbo Manifold Nut!!
« Reply #19 on: 10:08:59 PM / 18-Mar-09 »
Ha. I just took that stud out and now use a bolt in there with a lock washer and have not had the problem since. I also made a special little took that comes in real handy!
