Author Topic: My Build Story...The 12welve gets some Luv! (Project High Response)  (Read 42130 times)

Offline 8SixS12

  • Get it done already!
  • Full Member
  • ***
  • Location: Birmingham, AL
  • Posts: 613
  • Vehicle: 1986 Nissan 200SX
Re: My Build Story...The 12welve finally gets some Luv!
« Reply #40 on: 10:42:10 PM / 29-Nov-12 »
And if you want to keep the little baffle on the exhaust side with the ras, you will have to dermal one corner if I remember correctly.
Are you doing cams? Right now for the brief time I drove mine it had a great mid range with stock head and a gt2871
Yeah, I've seen it done before and yeah I'm doing mild cams.
Post Merge
And speaking of cams...


Crower stage 1 cams FYA!
« Last Edit: 10:55:33 PM / 29-Nov-12 by 8SixS12 »
"Sense is not always common" -self quote

My Build Thread: http://club-s12.org/retro4/index.php?topic=36053.0

Offline 8SixS12

  • Get it done already!
  • Full Member
  • ***
  • Location: Birmingham, AL
  • Posts: 613
  • Vehicle: 1986 Nissan 200SX
Block back from the machine shop...again.

A buddy of mine works at a machine shop had it square decked and resurfaced.  Looks like new!


Much better!
« Last Edit: 09:35:44 AM / 01-Dec-12 by 8SixS12 »
"Sense is not always common" -self quote

My Build Thread: http://club-s12.org/retro4/index.php?topic=36053.0

Offline Prolowtone

  • Mr. Clean
  • CONTRIBUTING MEMBER
  • S12 Guru
  • *****
  • Location: Langley, BC/ Calgary, AB
  • Posts: 2,546
  • Vehicle: 1985 Nissan 200SX
that is much better
I keep my car cleaner then my room
Fuck you then, I'll take my movies, box of chocolates, bottle of wine and chloroform somewhere else.
Adding an SSD to that is kinda like strapping a 3 inch stainless HKS exhaust on a geo metro.

Offline sideways_s12

  • CS12 OG
  • Moderators
  • S12 Guru
  • *****
  • Location: Las Vegas NV
  • Posts: 11,013
  • Vehicle: 1987 Nissan 200SX
  • Quit Fuckin around and start the car!
Looks good...

Offline 8SixS12

  • Get it done already!
  • Full Member
  • ***
  • Location: Birmingham, AL
  • Posts: 613
  • Vehicle: 1986 Nissan 200SX
Update to the parts bin:

Here's when my Ishihara-Johnson crank scraper / windage tray came in:



This will help with acceleration by getting that excess oil off the crank and free up some power by breaking up that nasty windage cloud that causes drag on the rotating assembly.
« Last Edit: 10:39:56 PM / 07-Dec-12 by 8SixS12 »
"Sense is not always common" -self quote

My Build Thread: http://club-s12.org/retro4/index.php?topic=36053.0

Offline darryn.

  • n00b
  • **
  • Location: Adelaide, Australia
  • Posts: 54
    • http://www.myspace.com/wowlookmumnohands
Liking where this is going man :) SR <3
I was thinking of using BC cams in mine but after a bit of research found the knock pin in the intake cam is out on them some up to 16* needing an adjustable gear to dial it into where it should be. Just a heads up incase you havent heard of it before. I read of people putting them in and loosing power because of it :/

Offline 8SixS12

  • Get it done already!
  • Full Member
  • ***
  • Location: Birmingham, AL
  • Posts: 613
  • Vehicle: 1986 Nissan 200SX
Liking where this is going man :) SR <3
I was thinking of using BC cams in mine but after a bit of research found the knock pin in the intake cam is out on them some up to 16* needing an adjustable gear to dial it into where it should be. Just a heads up incase you havent heard of it before. I read of people putting them in and loosing power because of it :/
Yeah, thanks for the tip but my cams are Crower, not Brian Crower (BC). Totally different cam manufacturers. I wanted to try them simply because nobody has any experience with them that I can tell. Sounds crazy I know but I'm not a bandwagon type of guy.
"Sense is not always common" -self quote

My Build Thread: http://club-s12.org/retro4/index.php?topic=36053.0

Offline sideways_s12

  • CS12 OG
  • Moderators
  • S12 Guru
  • *****
  • Location: Las Vegas NV
  • Posts: 11,013
  • Vehicle: 1987 Nissan 200SX
  • Quit Fuckin around and start the car!
Didn't know crower and brian crower were different companies are they cheaper than bc?

Offline darryn.

  • n00b
  • **
  • Location: Adelaide, Australia
  • Posts: 54
    • http://www.myspace.com/wowlookmumnohands
Oh yeah, I was always under the impression that they were the same company :P I thought it was strange because I had heard of crower being pretty well known for their good reputation and work/products, then when I read about the timing issue and that they were mass produced china cams it struck me as odd. Glad thats cleared up now haha.

What turbo are you running with the s1 cams? Sorry if Ive missed it in an earlier post :P

Offline 8SixS12

  • Get it done already!
  • Full Member
  • ***
  • Location: Birmingham, AL
  • Posts: 613
  • Vehicle: 1986 Nissan 200SX
This link should clear up the BC / Crower relationship:  http://www.briancrower.com/about.shtml

As for the turbo, I'll be running the s15 dual BB turbo that's on the CA18ET right now but if it's out of spec when I pull it out I'm going with either a Disco potato or the Tomei ARMS M7960 kit.  The T28BB should be fine though because I only ran it for about 6 months.
"Sense is not always common" -self quote

My Build Thread: http://club-s12.org/retro4/index.php?topic=36053.0

Offline 8SixS12

  • Get it done already!
  • Full Member
  • ***
  • Location: Birmingham, AL
  • Posts: 613
  • Vehicle: 1986 Nissan 200SX
Didn't know crower and brian crower were different companies are they cheaper than bc?
I wish. They are considerably more (probably why not many people run them).  Besides I had access to these and they have a great reputation with the muscle car guys so I figured why not.
Post Merge
Some more goodies came in:


ACT HD pressure plate and clutch disc

« Last Edit: 09:52:37 PM / 15-Dec-12 by 8SixS12 »
"Sense is not always common" -self quote

My Build Thread: http://club-s12.org/retro4/index.php?topic=36053.0

Offline D-sport S12

  • Sr. Member
  • ****
  • Location: Kelowna, BC, Canada
  • Posts: 1,072
  • Vehicle: 1986 Nissan S12
That's a nice feeling street clutch, drove a skyline with one like it, not to agrresive unlike my 4 puck
Jesse R

Keichi Tsuchiya: "I'm afraid if I raced you on the street I'd push you to your death."


Offline 8SixS12

  • Get it done already!
  • Full Member
  • ***
  • Location: Birmingham, AL
  • Posts: 613
  • Vehicle: 1986 Nissan 200SX
Yeah, my goal was to be able to enjoy the car. I don't want to feel like I'm working every time I step on the clutch pedal.  Besides, I'm pretty sure I won't be making anything close to the 372ft lb rating anyway.
Post Merge
I decided to go with the matching streetlite flywheel for the same reasons
« Last Edit: 06:16:56 AM / 17-Dec-12 by 8SixS12 »
"Sense is not always common" -self quote

My Build Thread: http://club-s12.org/retro4/index.php?topic=36053.0

Offline IggyEGuana

  • Builder - Driver
  • S12 Guru
  • *****
  • Location: Hawthorne, California, USA
  • Posts: 3,754
baller parts list adding up

Waylon Deno - Silhouette Autosports (check it out on facebook)
Drift Build Thread
Quote from: Arro
you sir are emblazoned with win.

Offline 8SixS12

  • Get it done already!
  • Full Member
  • ***
  • Location: Birmingham, AL
  • Posts: 613
  • Vehicle: 1986 Nissan 200SX
baller parts list adding up
I just want to spend the money where it counts.  I only want to do this once!

Post Merge
Believe it or not, I plan in using the oem intake and exhaust manifolds to take advantage of the new cam profiles and to save some funtickets in the process.  With that said I wanted to try out this new paint from KBS coatings. They are a new vendor that just got picked up where I work.

I talked to the reps and they say the spray will withstand about 1200 degrees and it won't peel or flake off.  I sprayed my exhaust manni with it and it looks like it was powdercoated.

I did have to hit it with a wire wheel to get all the surface rust off first and then wiped it down with some TSP to remove any left over oils and dust before spraying it.  Then I baked it in my barbecue grill @ 300 degrees.

I'm not a great painter but this thing has zero runs on it.  I think it came out pretty decent for a spray coating.

Post Merge
I'm thinking of doing the same to the intake manni as well but I'm not sure on the color scheme yet. You can bet it won't be blue, green and white though.
Post Merge
I'm almost done prepping my intake manifold and valve cover.

Problem is I just noticed that the baffle drain (Or what ever it's called) on the underside of the VC is broken.

Not really sure if it matters or not but it kind of makes me uneasy about using it. I found another one though but it sucks that I wasted all that time and energy getting off that ugly blue powder coat. BTW, CRC gasket remover works wonders on powdercoating. Spray it on and let it sit for a few then wipe it off - no BS! I used a platic scraper to avoid gouging the VC.
« Last Edit: 12:02:43 PM / 21-Dec-12 by 8SixS12 »
"Sense is not always common" -self quote

My Build Thread: http://club-s12.org/retro4/index.php?topic=36053.0

Offline axlegrease

  • Full Member
  • ***
  • Location: Atlanta, GA
  • Posts: 130
Nice build thread!!! Looks like its going along quite well! Maybe this will inspire me to get up off my lazy ass and throw the sr in my s12 too....  :yawn:

Offline 8SixS12

  • Get it done already!
  • Full Member
  • ***
  • Location: Birmingham, AL
  • Posts: 613
  • Vehicle: 1986 Nissan 200SX
Nice build thread!!! Looks like its going along quite well! Maybe this will inspire me to get up off my lazy ass and throw the sr in my s12 too....  :yawn:
Thanks for the kind words!  Yeah, getting off your duff is the hardest part.  More updates today....I hope.
Post Merge
Update: I started pulling off some of the front end trim to get ready to remove the fenders.

Found 26 year old dirt that accumulated behind the mud guards.


Fenders and hood off:

Once that was done, I realized that I needed to turn the car around in order to have enough room to pull the motor.


Thank god my CA18ET still runs!
Post Merge
Last time I'll see the 18ET in the 'ol bay.
Sad to see it go....can we get a moment of silence?.....

okay now that I'm over that, I can't wait to get it outta there!
« Last Edit: 02:04:31 PM / 05-Jan-13 by 8SixS12 »
"Sense is not always common" -self quote

My Build Thread: http://club-s12.org/retro4/index.php?topic=36053.0

Offline Jeremy A

  • Full Member
  • ***
  • Location: Las Vegas, NV
  • Posts: 739
  • Vehicle: 1984 Nissan 200SX
  • S12 Daily Driver
 :sniffles:

Offline BattleFairy

  • Full Member
  • ***
  • Location: Germany
  • Posts: 817
 :cry2:
Abandon all Hope
Project: Battle Fairy
Quote
Now, I won't be a dick like Battlefairy was.......

Offline sideways_s12

  • CS12 OG
  • Moderators
  • S12 Guru
  • *****
  • Location: Las Vegas NV
  • Posts: 11,013
  • Vehicle: 1987 Nissan 200SX
  • Quit Fuckin around and start the car!
Bye Bye single cam ca :(
